Purpose of the Diesel Heater
• Heating and maintaining the following warmth:
Crew and passenger compartments
• Freight compartments
• Ship’s cabins, driver cabs, and working cabs
• Recreational vans
• Pre-heating or de-misting windows
Based on its functional purpose, try not to use the diesel parking heater for the given applications:
• Drying or heating.
• Living organisms (animals or people) by blowing hot air straight at the subject.
• Directing hot air into containers
• Objects
• Long-term non-stop use. For example, pre-heating and heating of:
• Houseboats
• Hunting hut, weekend homes, and work huts
• Garages
• Residential rooms, among others.
Always make sure you use and operate the diesel heater within the range of application given above. The indications are from the manufacturer themselves. These are the “Operating guidelines” for every diesel heater.
Application of the Diesel Heater
Both the diesel air heater and the diesel water heater can function on their own. So the heaters can solo work as the vehicle’s engine. You can install them in the following automobiles. We base it on their heating output:
All types include cars
• Vans
• Buses
• RVs, Motorhome, Caravan
• Coaches
• Trucks.
• Construction machinery
• Boats, ships, and yachts
• Agricultural machinery
Technical Specifications (6KW)
-
Heat Power (KW)6KW max.
-
FuelDiesel
-
Rated Voltage12VDC, 24VDC
(10-32VDC) -
Rated Power Consumption (W)96W max.
-
Fuel Consumption0.65 l/h
-
Dimensions435 x 164 x 173 mm 17,1 x 6,4 x 6,8 inc
-
Working Temperature-40/+40
-
Quality ComplianceFCC, CE, RoHS
-
CERTIFICATIONECE R122ECE R10MIL-STD 461 F/GMIL-STD 810 GMIL-STD 1275 E
Technical Specifications (10KW)
-
Heat Power (KW)10KW max.
-
FuelDiesel
-
Rated Voltage24VDC
(18-32VDC) -
Rated Power Consumption (W)120W max.
-
Fuel Consumption0.80 l/h
-
Dimensions435 x 164 x 173 mm 17,1 x 6,4 x 6,8 inc
-
Working Temperature-40/+40
-
Quality ComplianceFCC, CE, RoHS
-
CERTIFICATIONECE R122ECE R10MIL-STD 461 F/GMIL-STD 810 GMIL-STD 1275 E
